Solar Panel CAD Drawings and DWG Details

Maintained by: SolarTyle Files: 8 DWGs and 1 PDF guide Library updated: 8 September 2026

This library supports early design coordination for architects, engineers, roofing contractors and installers. The integrated-roof drawings cover typical eaves, panel, ridge, boundary and layout information; the carport files are listed separately so the two design intents are not confused.

For fitting instructions, download the SolarTyle Installation Guide (PDF, 14 pages, 7.7 MB). This illustrated guide is for professional installer use only.

Use the Drawings as Reference Details

These downloads are reference resources, not project-specific construction approval. Before issue or installation, the appointed design team should confirm the latest applicable detail against the selected SolarTyle product, current instructions, structural design, roof build-up, fire strategy, electrical design, Building Regulations and site conditions.

Only files whose names include REV2 are described as revision 2 below. No revision is inferred for the remaining files. Contact SolarTyle technical support if the project requires a current detail, a different file format or confirmation of a specific interface.

  • Keep the original file name and revision reference in the project document register
  • Check dimensions and interfaces against the current SolarTyle data sheet
  • Coordinate roofing, structural, electrical and fire requirements before construction issue
  • Record project-specific departures rather than altering a reference detail without review

For specification support, visit the SolarTyle architect hub and review the available standards and certificates. A project team can also discuss a roof project with SolarTyle for an initial system discussion.

An installer fitting red SolarTyle modules at Moor Hall
An installer positioning a red SolarTyle module at Moor Hall


Coordinate the Detail Before Procurement

Early coordination helps the roof layout, module field, surrounding tiles, access and electrical routes form one workable package. Use the drawings to start that conversation, then obtain project-specific confirmation before relying on a detail for construction.

Download the Installation Guide

SolarTyle Installation Guide

Illustrated installation guidance for professional installers. Read the guide fully before starting work and contact SolarTyle technical support to confirm the applicable details for your project.

Format: PDF | Pages: 14 | Size: 7.7 MB
Audience: Professional installer use only

Download SolarTyle Roof DWG Details

Five direct-download reference details for the integrated solar roof. Approximate sizes are rounded to the nearest kilobyte.

Solar panel eaves detail

File: Solar-Panel-Details-Eaves.dwg
Format: DWG | Size: 216 KB

Solar panel flashings detail - REV2

File: Solar-Panel-Details-Flashings-REV2.dwg
Format: DWG | Size: 192 KB

Solar panel detail - REV2

File: Solar-Panel-Details-Panels-REV2.dwg
Format: DWG | Size: 176 KB

Solar panel ridge detail

File: Solar-Panel-Details-Ridge.dwg
Format: DWG | Size: 215 KB

Solar panel typical layout

File: Solar-Panel-Typical-Layout.dwg
Format: DWG | Size: 186 KB

Download Solar Carport DWG Concepts

Three concept files for carport layouts. These are separate from the SolarTyle integrated-roof details above.

Solar carport concept

File: Carport.dwg
Format: DWG | Size: 197 KB

Double solar carport concept

File: Carport-Double-1.dwg
Format: DWG | Size: 176 KB

Single solar carport concept

File: Carport-Single-1.dwg
Format: DWG | Size: 174 KB

  1. SolarTyle data sheet, version 3: current published module dimensions and technical parameters.
  2. SolarTyle product brochure, version 9: system and roof-package overview.
  3. Architect specification hub: design-stage SolarTyle information and project support.
  4. Technical support: request the applicable detail or discuss a project-specific interface.

Installation guide added on 8 September 2026; DWG library reviewed on 9 August 2026. Download availability does not make a drawing approved for construction or confirm that it is the latest applicable detail for a specific project.
